當前位置：中空玻璃打膠機的使用技巧
時間：2022-10-12 來源：http://www.txxfj.com/ 發布人：昌盛機械
中空玻璃打膠機在使用過程中或者停止時，會出現一些玻璃渣，原因是：膠嘴護套損壞，鋁槽深度檢測探頭行走劃到了玻璃，擋膠板或者刮膠板的前進力量太大。解決方法：重新換護套，調整探頭位置，讓探頭在鋁槽中間行走。調節前進氣缸的速度到合適，可以避免出現玻璃渣。
During the use or stop of the insulating glass gluing machine, there will be some glass slag. The reasons are: the rubber nozzle sheath is damaged, the aluminum groove depth detection probe moves and scratches the glass, and the forward force of the rubber baffle or the rubber scraper is too large. Solution: replace the sheath, adjust the position of the probe, and let the probe walk in the middle of the aluminum tank. Adjusting the speed of the forward cylinder to an appropriate value can avoid the occurrence of glass slag.
打膠的過程中，有時候還沒打完就開始后面的動作，這樣是很不好的，很容易損害玻璃，出現這種情況的原因：可能是因為機頭前面的光纖頭有遮擋物，或者可能是光纖頭螺母松動或傾斜。或者是表面有臟東西，或者是檢測的距離太小，行走時有波動，影響檢測。解決方法：清洗光纖頭，或者是固定好，或是清理玻璃表面，調整至合適的檢測距離。
In the process of gluing, sometimes the following actions are started before the gluing is finished. This is very bad and it is easy to damage the glass. The reason for this situation is that the optical fiber head in front of the machine head is blocked, or the nut of the optical fiber head is loose or inclined. Either there is dirt on the surface, or the detection distance is too small, and there is fluctuation when walking, which affects the detection. Solution: clean the optical fiber head, or fix it, or clean the glass surface, and adjust it to the appropriate detection distance.
運轉過程中總是有些不協調，各個動作之間不協調，出現原因：參數設置有誤，需重新設置參數。如果是氣動系統配件老化的話，就換一個新的。
There is always some incongruity in the operation process, and there is incongruity between various actions. The reason for this is: the parameter setting is wrong, and the parameter needs to be reset. If the pneumatic system parts are aging, replace them with new ones.
電機不穩定，時快時慢。原因：鋁槽不直，導軌不直或是滑動軸承損壞。
The motor is unstable, fast and slow. Cause: the aluminum groove is not straight, the guide rail is not straight or the sliding bearing is damaged.
中空玻璃打膠機主要是用于中空玻璃的密封，所以說中空玻璃的性能完全看中空玻璃打膠機。可是因為施工人員對機器的不夠了解，因此有時候打膠的結果不是很好，所以關于中空玻璃打膠機的具體操作注意的地方就很重要了。在清洗混膠器、膠嘴或混膠的時候，要把機頭劃至軌道的末尾，還要用膠板接住膠嘴流出來的膠，以防設備被污染。此外，打膠機在出廠時都有固定的參數，這個就是為了不懂得用戶來設計的。就算自己什么都懂了，也不要輕易的修改參數。在調整參數時，根據自己需要的參數設定，千萬不可隨意設定參數，以免控制器發出錯誤的信息，影響到打膠的質量、工程的進度，更有甚者會損毀設備。在沖洗混膠器、膠嘴或者混膠時，一定要先打開膠嘴控制的閥門，之后在打開供膠機。這個順序一定要記住。這是避免壓力劇增損壞設備或者出現安全事故。
The insulating glass gluing machine is mainly used for sealing the insulating glass, so the performance of the insulating glass depends entirely on the insulating glass gluing machine. However, because the construction personnel do not know enough about the machine, sometimes the results of gluing are not very good, so it is very important to pay attention to the specific operation of the insulating glass gluing machine. When cleaning the rubber mixer, rubber nozzle or mixing, draw the head to the end of the track, and use a rubber plate to catch the glue flowing out of the rubber nozzle to prevent the equipment from being polluted. In addition, the gluing machine has fixed parameters when it leaves the factory, which is designed for users who do not know. Even if you know everything, don't modify the parameters easily. When adjusting the parameters, set the parameters according to your own needs. Do not set the parameters at will, so as to prevent the controller from sending wrong information, affecting the quality of gluing and the progress of the project, and even damaging the equipment. When flushing the glue mixer, glue nozzle or glue mixing, be sure to open the valve controlled by the glue nozzle first, and then open the glue feeder. This order must be remembered. This is to avoid damage to equipment or safety accidents caused by pressure surge.
以上就是為大家介紹的有關中空玻璃生產線的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務http://qxu1608160335.my3w.com
The above is the detailed introduction of the insulating glass production line for you. I hope it will be helpful to you. If you have any questions, please contact us. We will provide services for you with an attitude of http://qxu1608160335.my3w.com
